The KW-869369 Bottom Rail is a structural and guiding element of a sliding gate system, designed to provide a smooth and stable path for gate rollers or wheels. Installed along the ground level, it supports the gate’s weight and ensures precise linear movement during opening and closing. By maintaining proper alignment, the bottom rail prevents derailment, reduces vibration, and extends the service life of the entire gate system.
Article No. | D (mm) | F (mm) | H (mm) | S (mm) | Length (mm) | Constant Load (KG) |
KW-869369.3M.16 | 15 | 9.5 | 13 | 3 | 3000 | 1000 |
KW-869369.3M.20 | 19 | 12 | 16 | 3.5 | 3000 | 1500 |
KW-869369.6M.16 | 15 | 9.5 | 13 | 3 | 6000 | 1000 |
KW-869369.6M.20 | 19 | 12 | 16 | 3.5 | 6000 | 1500 |
Download the submittal by clicking the button below.
| Finish | Galvanized |
|---|---|
| Material | Galvanized Steel |
