The KW-837337SB Half-Support Sliding Gate Wheel with U-Groove is a robust solution designed for classical sliding gates, offering reliable support and smooth operation across heavy-duty applications. The wheel features a U-shaped groove that provides optimal alignment with the track, ensuring precise guidance and preventing lateral movement. Equipped with a single weather-resistant bearing, it is built to withstand harsh outdoor conditions, reducing friction and enhancing long-term performance. The wheel is precision-machined, ensuring uniformity in size and groove shape for consistent rolling. Constructed from C40 steel, it delivers exceptional strength and wear resistance, making it perfect for high-traffic and demanding gate systems.
Article No. | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | I (mm) | L (mm) | M (mm) | N (mm) | P (mm) | R (mm) | S (mm) | Load (KG)** |
KW-837337SB.50.12 | 5.5 | 25 | Ø50 | 11 | 7 | 24 | 75 | 15 | 96 | 10 | 31 | 6.2 | 2 | 100 |
KW-837337SB.80.16 | 7.5 | 32 | Ø78 | 14 | 9 | 38 | 110 | 20 | 135 | 14 | 50 | 8.3 | 3 | 350 |
KW-837337SB.100.16 | 7.5 | 32 | Ø98 | 14.5 | 9 | 55 | 130 | 21 | 155 | 13 | 70 | 8.3 | 3 | 450 |
Download the submittal by clicking the button below.
| Finish | Galvanized |
|---|---|
| Material | Galvanized Steel |
