The KW-836336Y Heavy Duty Half-Support Sliding Gate Wheel with Y-Groove is a robust solution designed for classical sliding gates, offering reliable support and smooth operation across heavy-duty applications. The wheel features a Y-shaped groove that provides optimal alignment with the track, ensuring precise guidance and preventing lateral movement. Equipped with double weather-resistant bearings, it is built to withstand harsh outdoor conditions, reducing friction and enhancing long-term performance. The wheel is precision-machined, ensuring uniformity in size and groove shape for consistent rolling. Constructed from C40 steel, it delivers exceptional strength and wear resistance, making it perfect for high-traffic and demanding gate systems.
Article No. | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | I (mm) | L (mm) | M (mm) | N (mm) | P (mm) | S (mm) | Load (KG)** |
KW-836336Y.60 | 5 | 36 | Ø58 | 17 | 9 | 24 | 96 | 25 | 120 | 15 | 32 | 3 | 200 |
KW-836336Y.80 | 7 | 33 | Ø78 | 17 | 9 | 38 | 110 | 24 | 135 | 12 | 50 | 3 | 350 |
KW-836336Y.100 | 9 | 33 | Ø98 | 17 | 9 | 55.5 | 130 | 24 | 153 | 13 | 70 | 3 | 500 |
Download the submittal by clicking the button below.
| Finish | Galvanized |
|---|---|
| Material | Galvanized Steel |
