The Wall Support Bracket is a structural mounting component designed to securely fix the top rail of a hanging sliding gate system directly to a vertical wall or structural column. It provides strong lateral support, precise track alignment, and vibration-free stability, ensuring smooth and reliable operation of the hanging gate over long service life.
Article No. | A (mm) | B (mm) | B1 (mm) | C (mm) | S (mm) | L (mm) |
KW-5329/P | 46 | 50 | 50 | 20 | 4 | 60 |
KW-5329/N | 62 | 64 | 50 | 29 | 4 | 70 |
KW-5329/M | 55 | 70 | 50 | 22 | 4 | 70 |
KW-5329/L | 72 | 85 | 50 | 34 | 4 | 80 |
Download the submittal by clicking the button below.
| Finish | Galvanized |
|---|---|
| Material | Galvanized Steel |
